TP-2000C Series Laboratory Multi-channel Linear DC Power Supply 30V 3A and 30V 5A

TP-2000C Series Laboratory Multi-channel Linear DC Power Supply 30V 3A and 30V 5A

Laboratory multi-channel linear DC power supply 30V 3A and 30V 5A
Two independent adjustable outputs 0~30V/0~3A x2, 0~30V/0~5A x2
One fixed output 5V/3A x1
Constant voltage and constant current operations, auto CV and CC switch
Low ripple and noise, low temperature drift
Auto Series and Parallel tracking operations
High efficiency, high power density
Over load and reverse polarity protections
Dual-color four digital panel meters

Get a Quote

Download PDF

Details

TP-2303C and TP-2305C are multi-channel linear DC power supplies. They are laboratory grade linear DC power supplies, featuring low ripple and noise, low temperature drift and fast recovery time.

The master channel and the slave channel can be used either as a single output 30V 3A or 30V 5A, or used in tracking series mode for output 60V 3A or 60V 5A, or used in tracking parallel mode for output 30V 6A or 30V 10A. The DC output starts once the dual power supply is powered on.

The multi-channel linear DC power supplies are ideal for laboratory tasks that require ultra-low noise, fast response time and precise voltage control.

Hot models

TP-2303C, Laboratory Multi-channel Linear DC Power Supply 30V 3A
TP-2305C, Laboratory Multi-channel Linear DC Power Supply 30V 5A

Selection Guide for Multiple Outputs Laboratory Linear DC Power Supplies

Model	TP-2303E TP-2305E	TP-2303C TP-2305C	TP-2303K TP-2305K	TP-2303 TP-2305	TP-2303TK TP-2305TK
Output voltage	0~30V x2	0~30V x2	0~30V x2	0~30V x2	0~30V x2
Output current	0~3A x2 0~5A x2	0~3A x2 0~5A x2	0~3A x2 0~5A x2	0~3A x2 0~5A x2	0~3A x2 0~5A x2
Fixed output		5V/3A	5V/3A	5V/3A	5V/3A
Preset V&I					√
Output ON/OFF			√	√	√
Tracking operation	√	√	√	√	√
Dimension (WxHxD)	255x155x330mm			255x155x370mm
Weight	7kg/9kg	7kg/9kg	7kg/9kg	8kg/10kg	8kg/10kg
