25MHz 40MHz 60MHz 100MHz Dual Channel Arbitrary Waveform Generator (AWG)
Sampling rate 300MSa/s, vertical resolution 16 bits, waveform length 2M points
2 independent output channels at same frequency range
4.3-inch TFT LCD display
7 standard waveforms, 160 built-in arbitrary waveforms
16-order Harmonic waveform output
Modulations: AM, DSB-AM, FM, PM, ASK, FSK, PSK, BPSK, QPSK, 3FSK, 4FSK, OSK, PWM
Synchronous output of CH1 and CH2
Multiple I/O: waveform output, sync signal output, modulation input, 10MHz clock input/output and trigger input/output
Powerful arbitrary waveform editing PC software, support SCPI commands
80MHz counter, support measurement of frequency, period, duty cycle, positive pulse width and negative pulse width
Over voltage, over current, short circuit and reverse voltage protections
Interface: USB device, USB Host

Details

TFG3000 series are high performance dual channel function / arbitrary waveform generators (AWG), providing a wide frequency range from 1uHz to 25MHz, 40MHz, 60MHz, 80MHz and 100MHz respective to each model. Both channels are equipped with same frequency range.

The arbitrary waveform generator can output 7 standard waveforms (Sine, Square, Ramp, Pulse, Noise, Harmonic, DC), 160 built-in arbitrary waveforms and 16-order harmonic waveforms. Users can define output waveforms through arbitrary waveform editing PC software. Waveform data can be uploaded or exported to USB storage devices.

The arbitrary waveform generator is an essential instrument for precise and flexible signal generation, satisfying both the industry and education standard testing needs.

Typical Models:

TFG-3025: 1μHz~25MHz Dual Channel Arbitrary Waveform Generator (AWG)
TFG-3040: 1μHz~40MHz Dual Channel Arbitrary Waveform Generator (AWG)
TFG-3060: 1μHz~60MHz Dual Channel Arbitrary Waveform Generator (AWG)
TFG-3080: 1μHz~80MHz Dual Channel Arbitrary Waveform Generator (AWG)
TFG-3100: 1μHz~100MHz Dual Channel Arbitrary Waveform Generator (AWG)
