PCH 4kW Variable Voltage Programmable HV DC Power Supply 1000V 1500V 2kV 3kV 4kV 5kV 6kV 8kV 10kV
PCH 4kW Variable Voltage Programmable HV DC Power Supply 1000V 1500V 2kV 3kV 4kV 5kV 6kV 8kV 10kV
- 4kW HV programmable DC power supply
- Rated voltage from 1kV to 10kV
- Option for negative output voltage -1kV to -10kV
- Comprehensive customized solutions case by case
- 4 digits LED display for voltage and current
- Low ripple, high stability
- List mode function, Auto Run function,
- No overshoot during startup
- Adjustable voltage rise time
- Preset voltage and current
- Remote ON/OFF control
- Multiple protections: OVP, OTP, ACF and current limit protections
- Standard interface: RS232 & RS485, support ModBus-RTU commands
- Data record and export through PC control software
- Hot keys for data save and recall on PC control software
Details
In the PCH 4kW series are HV programmable adjustable DC power supply for laboratory. There are variable high voltage power supply 1000V 1200V 1500V 2kV 3kV 4kV 5kV 6kV 8kV and 10kV. The customized 1000V 4A 2000V 2A 4000V 1A 10kV 400mA are hot models programmable adjustable high voltage power supply for laboratory, factory and ATE system use.
The 4kW HV DC power supply has digital interface RS232 and RS485. The 4kW switching power supply also has option for analog interface for control and feedback, available with control signal 0-5V, 0-10V and 4-20mA.
The 4kW adjustable programmable power supply has no overshoot when output is turned on. It means no voltage peak.
The DC power supply 4kW can be made to customs power supply and OEM power supply.
Hot models
- PCH4000-10H: Programmable HV Power Supply 1000V 4A 4KW
- PCH4000-20H: Programmable HV Power Supply 2000V 2A 4KW
- PCH4000-40H: Programmable HV Power Supply 4000V 1A 4KW
- PCH4000-80H: Programmable HV Power Supply 8000V 0.5A 4KW
- PCH5000-10H: Programmable HV Power Supply 1000V 5A 5KW
- PCH5000-10H: Programmable HV Power Supply 2KV 2.5A 5KW
- PCH5000-50H: Programmable HV Power Supply 5000V 1A 5KW
