Twintex PCL 20V series programmable high current DC power supply utilizes a modular parallel architecture; a configuration of two units in parallel achieves a 20V 1000A output (factory-configured), while flexible expansion up to 20V 7800A (factory-configured) is possible to meet high-current testing requirements ranging from the kilowatt to the hundred-kilowatt level.
Specifically optimized for constant-current applications, the PCL 20V series programmable high current DC power supply offers exceptional stability, making it particularly suitable for continuous burn-in and performance verification of low-voltage, high-current devices such as those rated at 12V, 15V, or 18V.
Regarding safety, the units come standard with short-circuit current-limiting protection and offer an optional short-circuit shutdown function, providing protection for both the device under test and the power supply itself. Comprehensive control interfaces, including standard RS232 and RS485, support remote monitoring and system integration, while optional LAN and analog control interfaces facilitate easy integration into automated testing platforms.
With optimized thermal management and high current-sharing accuracy, the PCL 20V series programmable high current DC power supply ensures stable, long-term operation at full load, serving as an ideal power solution for sectors such as power semiconductors, supercapacitors, electric vehicle components, and energy storage units.
Three typical current ratings and their typical applications are listed in below.
20V 1000A 20kW Programmable High-Current DC Power Supply PCL20-1000:
- High-current device testing: Supports current-carrying capacity testing and burn-in for low-voltage, high-current semiconductor power devices (such as IGBTs and MOSFETs) rated at 12V, 15V, or 18V.
- University and research applications: Serves as general-purpose high-current testing equipment for university laboratories, research institutions, and testing agencies.
20V 3000A 60kW Programmable High-Current DC Power Supply PCL20-3000:
- High-voltage DC relay testing: Configures test setups for high-voltage DC relays that simulate automotive environments, meeting industry testing standards.
- Electric and industrial heating: Provides stable DC power for high-power industrial electric heating equipment.
20V 6000A 120kW Programmable High-Current DC Power Supply PCL20-6000:
- Electrical equipment temperature rise and load testing: Suitable for temperature rise tests on JP cabinets and distribution boxes, as well as current load and temperature rise testing for switches, cables, current transformers, and other electrical equipment.
- High-power inverter burn-in: Performs full-load burn-in and durability testing on high-power equipment such as large-scale inverters and industrial compressors.
