75W to 300W MINI DC Power Supply Adjustable Single Output 15V 5A 30V 5A 30V 10A and 60V 5A
75W to 300W MINI DC Power Supply Adjustable Single Output 15V 5A 30V 5A 30V 10A and 60V 5A
- MINI DC power supply 30V 5A, 30V 10A and 60V 5A
- 3 digits LED display (S models)
- 4 digits LED display (D models)
- Adopts post-stage voltage regulation technology
- Constant voltage and constant current operations
- Auto CV/CC switch
- Encode knobs for precise voltage and current adjustment
- Preset voltage and current when output is OFF
- Multiple protections: OVP, OCP, OPP, OTP and short circuit protection
- Adjustable OVP, OCP and OPP range
- Panel lock function
- Beeper alarm function
- Output ON/OFF control
Details
The DS series is digital control switch mode MINI DC power supply with single output. The MINI DC power supply adopts switching power supply post-stage voltage regulation technology. Rated power is available from 75W to 300W, and rated voltage is 30V & 60V. The DS series are meant for a low-cost DC power supply which can be widely used in education and electronic industry.
| Model | DS-305S | DS-3010S | DS-605S | DS-305D | DS-3010D | DS-605D | |
| Rated output | 30V 5A | 30V 10A | 60V 5A | 30V 5A | 30V 10A | 60V 5A | |
| Rated power | 150W | 300W | 300W | 150W | 300W | 300W | |
| Display meter | 3 digits LED display | 4 digits LED display | |||||
| Display range | Voltage | 00.0-32.0V | 00.0-32.0V | 00.0-62.0V | 00.00-32.00V | 00.0-32.00V | 00.0-62.00V |
| Current | 0.00-5.10A | 0.00-9.99-10.2A | 0.00-5.10A | 0.000-5.100A | 0.000-9.999-10.20A | 0.000-5.100A | |
