PCH 600W Compact Programmable High Voltage DC Power Supply 1000V 1200V 1500V 2000V 3000V
PCH 600W Compact Programmable High Voltage DC Power Supply 1000V 1200V 1500V 2000V 3000V
- Programmable high voltage DC power supply 600W
- Rated voltage 1000V, 1200V, 1500V, 2000V, 3000V
- Option for negative polarity -1000V, -1200V, -1500V, -2000V, -3000V
- Low ripple 0.1%FS
- Compact design, 2U half width cabinet
- List mode function, Auto Run function,
- No overshoot during startup
- Soft start by hardware, and adjustable voltage rise time by software
- Remote ON/OFF control
- Preset function, setting of voltage and current with output open circuit
- Multiple protections: OVP, OTP, ACF and current limit protections
- Standard interface: RS232 & RS485, support ModBus-RTU commands
- Data record and export through PC control software
- Hot keys for data save and recall on PC control software
- Same output ratings available with 2U full size rack mount cabinet
Details
The PCH600-S series are 600W programmable high voltage DC power supplies, with compact design in 2U half rack. There are four voltage ratings 1000V, 1200V, 1500V, 2000V and 3000V. Each can be made either positive polarity or negative polarity. It means that only one polarity is available in a power supply. To save space, two power supplies can be built into a 2U full rack as shown in photos on the right. Each power supply is independent in AC input, DC output and remote control.
For higher voltage at 600W power level in the same product family, please refer to PCH600 series. Voltage ratings is available from 1kV to 12kV a 2U full rack.
Hot models
- PCH600-10HS: 1000V High Voltage DC Power Supply 600W
- PCH600-12HS: 1200V High Voltage DC Power Supply 600W
- PCH600-15HS: 1500V High Voltage DC Power Supply 600W
- PCH600-20HS: 2000V High Voltage DC Power Supply 600W
- PCH600-30HS: 3000V High Voltage DC Power Supply 600W
Programmable High Voltage DC Power Supply 600W 1200W
Model |
Rated Output | Model | Rated Output | |||||
| V | A | W | V | A | W | |||
| PCH600-10HS | 0~1000V | 0~600mA | 600W | PCH1200-10HS | 0~1000V | 0~1200mA | 1200W | |
| PCH600-10HSN | -200~-1000V | 0~600mA | 600W | PCH1200-10HNS | -200~-1000V | 0~1200mA | 1200W | |
| PCH600-12HS | 0~1200V | 0~500mA | 600W | PCH1200-12HS | 0~1200V | 0~1000mA | 1200W | |
| PCH600-12HSN | -240~-1200V | 0~500mA | 600W | PCH1200-12HNS | -240~-1200V | 0~1000mA | 1200W | |
| PCH600-15HS | 0~1500V | 0~400mA | 600W | PCH1200-15HS | 0~1500V | 0~800mA | 1200W | |
| PCH600-15HSN | -300~-1500V | 0~400mA | 600W | PCH1200-15HNS | -300~-1500V | 0~800mA | 1200W | |
| PCH600-20HS | 0~2000V | 0~300mA | 600W | PCH1200-20HS | 0~2000V | 0~600mA | 1200W | |
| PCH600-20HSN | -400~-2000V | 0~300mA | 600W | PCH1200-20HNS | -400~-2000V | 0~600mA | 1200W | |
| PCH600-30HS | 200~3000V | 0~200mA | 600W | PCH1200-30HS | 200~3000V | 0~400mA | 1200W | |
| PCH600-30HSN | -600~-3000V | 0~200mA | 600W | PCH1200-30HNS | -600~-3000V | 0~400mA | 1200W | |
| Weight | 212.5Wx88Hx340D mm (1/2 2U) | |||||||
| Dimensions | Approx 5kg | |||||||
| AC Input | 1φ3W, 220V±10% 47~63Hz | |||||||
