TP-S Series Switching DC Power Supply High Power 3kW 5kW 6kW 30V 60V 100V up to 800V

TP-S Series Switching DC Power Supply High Power 3kW 5kW 6kW 30V 60V 100V up to 800V

Rated voltage 15V 30V 60V 80V 100V 120V 150V 200V 250V 300V 400V 500V 600V 800V
Max. output power ranging from 200W to 6kW
Max. output voltage 800V, Max. output current 200A
Applying advanced PWM control technology
Compact design and light weight (3~9kg)
Constant voltage and constant current operations
Auto CV/CC switch
Coarse and Fine control for voltage and current
Over voltage, over current, over temperature and over power protections
Adjustable OVP range, OCP fixed 105% of Max. current range
Intelligent temperature control cooling fan
Customized specifications and functions acceptable

Get a Quote

Download PDF

Details

The TP-S series switch mode DC power supply is high voltage switching lab power supply available with three different size of cabinets: M size, L size and XL size. In this XL size cabinet, the high voltage high frequency DC regulated power supply is available with high power supply up to 3kW, 4kW, 5kW and 6kW DC power source. The high power switching power supply has maximum voltage from 15V, 30V, 60V, 80V, 100V, 120V, 150V, 200V, 250V, 300V, 400V, 500V, 600V and 800V. The DC power supply high current output is up to 100A, 120A, 150A and 200A. The DC high voltage power supply can be made to custom power supply and OEM power supply.
